2.7 LPD_DIO Selection (JP1)
LPT DIO
JP1
Function
Off LPT
On DIO
2.8 AT/ATX Selection (JP2)
ATX
AT
JP2
Function
Off ATX
On AT
2.9 Touch Screen Selection (JP3)
4,8 Wire 5 Wire
JP3
Function
Off 5
Wire
On 4.8
Wire
