Technical details
Electrical data 773857 773858
Insulation resistance 10 MOhm 10 MOhm
Environmental data 773857 773858
Ambient temperature
Temperature range 0 - 60 °C 0 - 60 °C
Storage temperature
Temperature range -25 - 70 °C -25 - 70 °C
Condensation during operation Not permitted Not permitted
Protection type
Mounting (e.g. cabinet) IP54 IP54
Housing IP20 IP20
Mechanical data 773857 773858
Plug connector X1 15-pin male D-Sub connector 15-pin male D-Sub connector
Plug connector X2 15-pin female D-Sub connector 15-pin female D-Sub connector
Plug-in connector X3 8-pin RJ45 male connector 8-pin RJ45 male connector
Housing material X1 Nickel steel, tin-plated Nickel steel, tin-plated
Housing material X2 Nickel steel, tin-plated Nickel steel, tin-plated
Housing material X3 PVC PVC
Material of contact surface Au Au
Pin material Cu alloy Cu alloy
Socket material Cu alloy Cu alloy
Mating cycles X1 50 50
Mating cycles X2 50 50
Mating cycles X3 750 750
Cable length L 2,50 m 1,50 m
Colour of external cable insulation Grey Grey
Cable insulation material PVC PVC
Suitable for drag chains No No
Cable diameter 6,10 mm 6,10 mm
Conductor cross section 0,14 mm² 0,14 mm²
Conductor cross section AWG 26 26
Wire colour In accordance with TIA/EIA 568 B In accordance with TIA/EIA 568 B
Shielding Yes Yes
Wire layer separation Yes Yes
No. of wires 8 8
Cable approval UL UL
Approval for plug connector X1 UL94 V-0 UL94 V-0
Approval for plug connector X2 UL94 V-0 UL94 V-0
Approval of plug-in connector X3 UL UL
Material
Housing TPE-SEBS UL 94 HB TPE-SEBS UL 94 HB
