Specifications
Bandwidth 6.75Gbps
Ports
Video input
Video output
Audio output
Ethernet
IR IN
Firmware/Control
AT-HD4-V41
4 x HDMI
1 x HDMI
1 x S/PDIF
1 x LAN
1 x 3.5mm
1 x 9pin (RS-232)
AT-HD4-V42
4 x HDMI
2 x HDMI
2 x S/PDIF
2 x LAN
1 x 3.5mm
1 x 9pin (RS-232)
Power Consumption 4.1W
Audio HDMI
Passes up to Dolby TrueHD
or DTS-HD Master Audio
S/PDIF
Passes up to Dolby Digital
or DTS 5.1
Resolution Video: up to 1080p
VESA: up to 1920x1200 (Reduced Blanking)
Dimensions 9.5 x 4.35 x 2 in
240 x 110 x 50 mm
Weight 1.8 lbs
0.81 kg
Temperature Operating
32°F to 104°F
0°C to 40°C
Storage
-4°F to 140°F
-20°C to 60°C
Certifications CE, FCC, RoHS, cULus for power supplies
