INTRODUCTION
PACKAGE CONTENTS:
FEATURES:
Atlona Technologies’ AT-HD-V22M is a 2x2 HDMI Matrix Switcher with audio designed to work as a
switcher for multiple Audio/Video sources and displays. This Atlona unit is capable of switching HDMI
signals between two sources and two displays. Because it is a matrix switch, any or all of the 2 inputs
can simultaneously be switched to any or all of the outputs. This devise will support high definition video
in multiple resolutions of up to 1080p or 1920x1200. This unit has quick and easy installation. With
manual, RS232, as well as IR Remote control options, Atlona’s AT-HD-V22M Matrix Switcher is HDCP
Compliant making it is perfect for all HDMI devices, PC monitors, Plasma TV displays and HDTVs.
• 2x2 HDMI Matrix Switcher (AT-HD-V22M)
• Instruction Manual
• IR Remote Control
• Universal AC/DC power adapter: 12VDC
• 19 inch Ear mount pair
• IR Extender receiver
• RS232 package (RS232 DVD Drive & RS232 Cable)
• Switches HDMI Video signal with Audio between 2 sources and 2 displays.
• Matrix Switch: each input can be directed to any or all outputs at the same time
• Quick and easy installation
• HDMI digital video/audio format, DVI format and HDCP compliant
• Supports link speeds of up to 2.25 Gbps (link clock rate of 225 MHZ)
• Supports wide range of PC resolutions from XGA to UXGA 1600x1200 and HDTV/DTV
resolutions 480i/480p, 576i/576p, 720p, 1080i, 1080p, and 1920x1200
• Compatible with all HDMI devices, PC monitors, Plasma TV display and HDTV
• Supports Digital Video TMDS formats in Deep Color 12bits
• Support IR Remote and IR Extender with distance 300M Maximum.
• Various User Interface control:
• IR remote control
• Manual controlled by Front Panel button
• Attached Window based control software for Desktop or NB control by RS232 port
• Automatically scanning input status by LED on front panel
