INTRODUCTION
APPLICATIONS
Atlona AT-HD-V12x2 and AT-HD-V16x2 are High Performance HDMI switchers. The Atlona 12x2 and
16x2 switchers are equipped with HDMI re-clocking technology which allows user to use long distance
HDMI cables on the inputs and output.
The 12x2 and 16x2 HDMI switchers are based on the latest HDMI IC and therefore capable of fully dis-
playing uncompressed digital video with resolutions up to 1920x1200 or 1080p along with High Resolu-
tion Audio up to Dolby True HD and DTS master and full 3D.
The Atlona 12 by 2 and 16 by 2 HDMI switchers are featured with a dual HDMI output (non-matrix). Both
outputs are active and will only output the same exact content at all the time (second output is duplicat-
for Residential applications.
Both Switchers are controllable though front panel, IR remote or RS232 interface.
Conference/Board-room:
As HDMI interface becoming more and more popular, most computers, DVD
players, media servers, cables boxes, etc… are now equipped with HDMI interfaces. It is very common
that a good size board-room or a conference room will need 12 or even 16 hdmi inputs to be able to
connect all of the sources needed. The switchers are equipped with a dual HDMI (non-matrix) outputs
which will allow user to connect both a TV and a Projector at the same time. Both models are featured
.
s
t
u
p
n
i
n
e
e
w
t
e
b
h
c
ti
w
s
o
t
m
e
t
s
y
s
l
o
rt
n
o
c
y
tr
a
p
d
r
3
a
f
o
e
s
u
a
s
w
o
ll
a
h
c
i
h
w
,
s
l
o
rt
n
o
c
R
I
d
n
a
2
3
2
S
R
h
ti
w
QA:
DVD player, Computer, Media Server companies would certainly need at least 12 or 16 hdmi input
switchers to be able to test their equipment either before product shipment or during RMA procedures.
The Atlona HD-V12x2 or 16x2 are perfect for such an application as they are fully capable of passing
highest resolutions up to 1920x1200 or 1080p, latest audio formats up to Dolby True HD and DTS-
Master and even all 3D formats.
PACKAGE CONTENTS
• 1 x AT-HD-V12x2 or AT-HD-V16x2
• Set of Rack Ears
• 1 x 12v Power supply (Universal 110/240V)
• RS232 Cable
• IR Cable
• 1 x Instructions manual
