Introduction / Safety information
Power Manager
Q
Introduction
Please make yourself familiar with the
product before use. Read the following
operating instructions and safety infor-
mation carefully. Only use the device as described
and for the specified purposes. Keep these instructions
and hand them to others when giving the device
away.
q
Intended use
The device is designed to switch on / off up to
6 electric appliances. Additionally, the device is a
surge protector. The PMA USB DE V2 model is ad-
ditionally equipped with an USB hub and a socket
for 5 V power adaptors. Other usage or modifica-
tions of the device are not intended and may cause
severe hazards. The manufacturer assumes no
liability for damages caused by improper use. The
device is not designed for professional use.
q
Included in delivery
1 Power Manager
1 USB cable (for PMA USB DE V2 model)
1 Operating instructions
q
Description of components
PMA USB DE V2 model (figures A + B I)
1
Master ON / OFF switch
2
LED
3
ON / OFF switch for each appliance
4
USB port
5
Power adaptor socket
6
USB cable connection
7
Power socket
PMA DE V2 model (figures A + B II)
1
Master ON / OFF switch
2
LED
3
ON / OFF switch for each appliance
7
Power socket
q
Technical data
Type:
PMA DE 3516 V2 /
PMA USB DE
3516 V2
Supply voltage:
230 V~ / 50 Hz
Total output:
max. 16 A /
3500 W
SPD as per
EN 61643-11:
Type 3
Highest continuous voltage U
C
: 250 V~ / 50 Hz
Combined surge U
0C
(L-N):
10 kV
Combined surge U
0C
(L / N-PE): 10 kV
Protection level Up (L - N):
1,8 kV
Protection level Up (L- / N-PE): 1,8 kV
Power adaptor socket:
1.4 / 3.5 / 9 mm
5 V / 2.5 A DC
Power cord length:
2 m
Dimensions:
approx.
38 x 6 x 29.5 cm
(W x H x D)
Mass:
1.6 kg
Ambient conditions:
Temperature:
+ 5 °C - + 40 °C
Relative humidity:
max. 90 %
Safety information
Read all safety information and
instructions. Failure to observe the safety information
and instructions may cause electric shock, fire and /
or severe injury.
