Brennenstuhl Solar LED External Light SOL WL 02007 2xLED 30lm Colour Stainless steel - Manual (Page 5)

5
D
Instructions for installation and use
SOL WL 02007 Solar Wall Light
We‘d like to thank you for purchasing this product�
Please familiarise yourself with the product before using it for the first time. Read the following
instructions and safety notes carefully. Use the device as described and for the specified purposes
only. Do not throw away these instructions. Include all documentation if giving the device to a
third party.
PARTS LIST
1. Solar panel
2. PIR sensor (motion detector)
3. Mounting screw 2x
4. LED
5. Battery compartment (back side)
6. AUTO / OFF switch (back side of lamp)
7. Mounting eyes
1
2
3
4
6
7
5
LOCATION OF THE SOLAR WALL LIGHT
1. For best results the solar module should be placed in a location that receives direct sunlight
and is not covered or shaded.
2. Make sure the solar wall light is not subject to interference from other light sources. Otherwise,
the lamp will not light up at dusk.
3. For optimal operation the solar wall light must be charged in sunny weather for a period of at
least 2 – 3 days.
4. When looking for a suitable location, make sure the horizontal detection range is approx. 90º
within a range of approx. 5 metres (as depicted in the following illustration).
90°
90°
5m
