Operating Instructions
SOL WL 02007 Solar Wall Light
INSTALLATION INSTRUCTIONS
Wall Installation
1. Carefully remove the solar wall light and all other parts from the packaging.
2. Find a suitable location for your solar wall light. It can be mounted on an exterior wall, a stair
tread or even a wooden post.
3. For installation on masonry, start by drilling holes for the plugs and the attachment screws.
Insert the plugs (included), making sure they are flush with the surface. The screws must
protrude from the surface by at least 5 mm in order to attach the light.
4. Hook the lamp‘s mounting eyes over the screw heads. Check that the solar wall light is firmly
attached.
ACTIVATION
1. The AUTO / OFF switch
6
is located on the back of the solar wall light. The lamp will light up
continuously after dark if the AUTO / OFF switch is set to AUTO.
2. The light features 1 LED for standby lighting; an additional LED is switched on if the motion
detector is triggered.
3. When the switch is in the OFF position the lamp does not light up, although the battery will
continue to charge during the day.
4. The output of the solar wall light will vary depending on the season. The light will stay on
longer after a sunny day than after an overcast day.
REPLACING THE BATTERY
For best results the rechargeable battery should be replaced every 24 months�
1. Remove the screws on the back of the solar wall light.
2. Remove the old battery. Make sure the new battery is a LiFePO4 3.2 V/500 mAh rechargeable
battery.
3. Insert the new battery into the battery compartment, paying close attention to correct polarity.
4. Close the battery compartment.
TROUBLESHOOTING
If your solar wall light fails to light up despite following the instructions above please use the
following troubleshooting steps:
1. Make sure there is no interference from another light source.
2. Make sure your solar wall light is not in the shade during the day.
3. Make sure the switch is set to AUTO.
4. Check whether the battery has been inserted correctly.
