Chapter 2: Jumpers and Connectors
Console Pin Header
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP5
1 3
Pin Description
1 SP_RTS1_R
2 SP_CTS1_R
3 SP_CTS1_CON
Pin Function
1-2 RTS to CTS
2-3 Normal
