FT040DB Series Installation & Operation Manual
www.ot-systems.com 15
(6) Specifications
MODELS*
PARAMETERS
FT040DB-SSTR(RT)SA
FT040DB-SSTR(RT)
(Single-Mode)
FT040DB-SSTR(RT)LSA
FT040DB-SSTR(RT)L
(Single-Mode)
FT040DB-SMTR(RT)SA
FT040DB-SMTR(RT)
(Multi-Mode)
OPTICAL
No. of Fiber / Connector 1 / ST (or FC) 1 / ST (or FC) 1 / ST (or FC)
Wavelength 1310/1550 nm 1550/1310 nm 1310/1550 nm
Optical Power Budget 17 dB 24 dB 23 dB
Max Distance (km) 40 60 4
DATA
Channel / Connector 4 / 7-pin Screw Terminal
Direction Bi-directional (Duplex)
Electrical Format RS232, RS422, RS485 (2-wire, 4-wire) Tri-state
Transmission Rate 0~256 Kbps
POWER
Power consumption 12VDC @ 3.6W
Power Supply Standalone unit: FT/PA12V DC Adaptor
Card module: Powered by FT-C18 chassis
Connector (Standalone unit) 2-pin Screw Terminal
PHYSICAL
Weight Standalone unit: 0.78 kg Card module: 0.28 kg
Dimensions (W x H x D) (mm) Standalone unit: 156 x 50.5 x 223 (MAX)
Card module: 148 x 41 x 213 (MAX)
ENVIRONMENTAL
Operating Temperature -40
o
C ~ +75
o
C
Storage Temperature -40
o
C ~ +85
o
C
Relative Humidity 0 ~ 95% non-condensing
MTBF >100’000 Hours
*
If the optical connector is FC type, the suffix in the model number will be “-FXX”. Eg. FT040DB-FSTR
