IF THE OVEN IS NOT UP TO
TEMPERATURE IT WILL SHOW THE
HEATING SCREEN.
WAIT FOR THE OVEN TO REACH
TEMPERATURE
WHEN THE OVEN IS AT THE
CORRECT TEMPERATURE, THE
“READY” SCREEN WILL SHOW.
1. OPEN DOOR AND LOAD PRODUCT.
2. CLOSE THE DOOR FULLY.
3. PRESS “START”
TIP
TO HELP TO KEEP THE OVEN HOT,
TRY NOT TO KEEP THE DOOR OPEN
MORE THAN NEEDED
THIS SCREEN WILL SHOW WHILE
THE PRODUCT IS BAKING
SET TEMPERATURE
TEMPERATURE PROFILE BAR
BAKE TIME PROGRESS BAR
BAKE TIME LEFT
5
HEATING SCREEN
READY SCREEN
IF THE OVEN IS TOO HOT FOR THE TEMPERATURE
CHOSEN, THE SCREEN WILL TELL YOU TO OPEN THE
DOOR TO AID COOLING.
NOTE
The actual temperature shown will rise and fall
above and below the set temperature as the
oven cools and reheats. This is not a fault
ACTUAL OVEN
TEMPERATURE
BAKE PHASE
(WHEN USED)
COUNTDOWN
TIMER TO
TURN PANS
SEE NEXT PAGE
