Video Loop-Out
If a 75 Ohm load is connected to the “Loop
Output”, then jumper W2 must be removed from
inside the case of the C2YC, or the resulting
video signal will be double terminated.
Specifications
Input/Output: 1 Volt Standard Video
Input Connector: Composite Video, BNC
Input Impedance: HiZ or 75 Ohms 1%
Bandwidth: 10MHz @ 0.5 dB
Output Impedance: 75 Ohms 1%
Output Connector: 4 pin MiniDIN
Output Protection: Open or Short, infinite
duration
S/N: 60 dB
Size: 4.1W x 1.5H x 5.5D inches
DC Powered: 11-14 Vdc
Wall Module: 120VAC 60Hz, 12Vdc
(included) 500mA, UL Listed
Warranty: One Year Parts and Labor
Composite to Y/C Converter
3
