DIP Switch Function
SW1-#1 Open Enabled Sync
Amplitude Test
(Low Amplitude Detect)
SW1-#2 Open Enabled Vertical
Interval Sync Test
(White Noise Detect)
SW1-#3 Open Enabled Frame Signal Test
(Progressive Scan Detect)
SW1-#4 Open Resample Video Tests
(Gives 4 second delay
before switching)
Options: ID, Rack Mount
Specifications
Output: 1 volt standard NTSC
Output Impedance: 75 Ohms 1%
Sync Tip: -40 IRE
Color Burst: ±20 IRE (3.579545 MHz)
Setup: 7.5 IRE
Tone Output: 1 volt, 1 kHz, 0 dBm,
1% THD (Mono)
Video Connectors: BNC
Audio Connectors: 4 Pin MiniDIN
Output Protection: Open or Short,
infinite duration
SMPTE Bars:
Fully Saturated 75% Bars (gray, yellow, cyan,
SG-8 Loss of Signal, Audio/Video, ID Inserter 6
