green, magenta, red, blue)
Reverse Blue Bars (blue, black, magenta, black
cyan, black, gray)
100 IRE White Bar
-I and +Q signals
Pluge pulse signal: Whiter than Black at 11.5
IRE, Black at 7.5 IRE,
Blacker than Black at 3.5 IRE
Black Burst: Sync, Color Burst
and 7.5 IRE Setup
Wall Module: 120 Vac 60 Hz, 12 Vdc
(included) 500 mA, UL Listed
DC Powered: 11—18 Vdc
Warranty: 1 Year Parts and Labor
