Appendix
Installation
Stacking kit
Door reversal
To make it easier to load or unload the laundry the door can be reversed. This operation must be
carried out by qualified personnel .Please contact the nearest our Service Centre. This will be a
chargeable option.
Any electrical work required to install this appliance should be carried out by a qualified electrician
or competent person.
Electrical connection
THIS APPLIANCE MUST BE EARTHED.
Warning
Before switching on, make sure the electricity supply voltage is the same as that indicated on the
appliance's rating plate.
Should the plug need to be replaced for any reason, proceed as described below.
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow-Earth
Blue-Neutral
Brown-Live
The wire coloured green and yellow must be connected to the terminal marked with the letter
or by the earth symbol or coloured green and yellow.
The manufacturer declines any liability should this safety measure not be observed.
That adequate ventilation has to be provided to avoid the back flow of gases into the room from
appliances burning other fuels, including open fires.
For appliances with ventilation openings in the base, that a carpet must not obstruct the openings.
It is important not to connect the vent hose to, for example, a cooker hood, or a chimney or
flue pipe designed to carry the exhaust from a fuel burning appliance.
Note that to avoid condensation problems, it is essential that the dryer be fitted with the flexi-
ble hose to carry its auste outside the kitchen.
In order to prevent the appliance from overheating, it is important that the steam exhaust is
unobstructed.
If the dryer is fitted next to kitchen units, make sure that the vent hose is not squashed. If
the hose is partially squashed, drying efficiency will be reduced, resulting in longer drying times and
higher energy consumption. If the hose is completely squashed, the safety cut-outs with which the
machine is fitted may operate.
When operating the tumble dryer, the room temperature must not be lower than +5°C and
higher than +35°C, as it may affect the performance of the appliance.
