Inlstallation instructions
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for correct
installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer and
bottom of upper plate should be at least 3mm.
Laundry
Tub
Washer
approx.
2cm
Drain Hose
Removing transit bolts
1. Before operating the washer, remove the transit
bolts(4ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 4 bolts with the 10mm hex wrench
or spanner or cross-tip screwdriver. Keep the 4
bolts for a later time.
• When the appliance is transported, transit bolts
will be re-used.
3. Close the holes with the cap holders supplied.
