Operate Washing Machine Operate Washing Machine
Washing Clothes at first time
Before washing clothes at first time, the washing machine shall be operated in
one round of the whole procedures without clothes in as follows:
1.Connect power source and water.
2.Put a little detergent into the box and close it.
3.Press the button “Power”.
4.Press the button “Start/Pause”.
The drawer is separated as follows:
I: Pre-detergent or washing powder.
II: main detergent, softener, pre-dip,
bleaching or decontaminating products.
: washing additive, such as fabric softener or tackifier.
Put detergent into washing machine.
1.Pull out the drawer.
2.Fill pre-detergent into Case I (when necessary).
3.Fill detergent into Case II.
4.Fill softener into Case (when necessary).
Notes:
As for the agglomerated or ropy detergent or additive, before they are poured into the detergent box,
it is suggested to use some water for dilution to prevent the inlet of detergent box from being blocked
and overflowing while filling water.
Start up washing machine
Connect the power. Check if water pipes are connected properly. Open the tap completely.
Put in the clothes to be washed and fill in the detergent and tackifier. Then press the button
“Power”,Select the proper procedures and functions and press the button “Start/Pause”.
Select the procedure
The proper washing procedures shall be selected according to the types, quantities, and
dirtiness of the clothes to be washed in combination with the following washing
temperature table.
Ⅰ Ⅱ
90 C
60 C
40 C 20 C
Cold water ,
Seriously besmirched, pure white cotton or flax (for example: coffee
table cloths, canteen table cloths, towels, bed sheets)
Moderately besmirched, colorful flax, cotton and synthetic articles
with certain decolorizing degree (for example: shirts, night pajamas;
Slightly besmirched, pure white flax (for example: underwear)
Normally besmirched articles (including synthetic and wool)
First, turn the rotary switch to select the corresponding procedures according to the types
of textiles.
Second, select the proper temperature according to the dirtiness. Generally, the higher
the temperature is, the more the power is consumed.
Last, select the proper revolution speed. The higher the revolution speed is, the drier the
textiles are spun, but higher the noises will also be increased.
The surfaces of delicate textiles will have wrinkles and the working life of washing
machine will be shortened.
PLEASE NOTE: to protect the clothes, the lower revolution speed shall be selected for delicate
textiles. The main washing procedures depend on the types of the clothes to be washed. The main
washing troubles can be selected as follows:
- Cotton
You can select this procedure to wash the daily washable clothes. The washing period
is quite long with quite strong washing intensions. It is recommended to wash the daily
cotton articles, for example: bed sheets, quilt covers, pillowcases, gowns, underwear etc.
- Synthetic
You can select this procedure to wash the quite delicate clothes. The procedure is shorter
compared with that for cottons and the washing intension is quite gentle. It is
recommended to wash synthetic articles, for example: shirts, coats, blending. As for
curtains and laced textiles, the procedure “Synthetic ” shall be selected. While
washing the knitting textiles, detergent quantity shall be reduced due to its loose string
construction and easily forming bubbles.
- Wool
You can select this procedure to wash the wool textiles labeled with “Machine Wash”.
Please select the proper washing temperature according to the label on the articles to
be washed. Furthermore, the proper detergent shall be selected for wool textiles.
- Underwear
Underwear cycle which is specially made for washing underwears is more demanding
on rinsing strength and will operate one more time than other cycles.
- Quick
This procedure is suitable for washing few and not very dirty clothes quickly.
- Cotton Intensive
To increase the washing effects, main additional washing time is increased.
It is recommended to wash the clothes for babies or worn by the persons with allergic skin.
- Spin
Separate Spin Procedure. Soap water or rinse water shall be drained out before spinning.
- Drum Clean
This cycle is specially set in this machine to clean the drum and tube. It applys 90 C
high temperature sterilization to make the clothes washing more green. When this
procedure is performed, the clothes or other washing cannot be added. When proper
amount of chlorine bleaching agent is put in, the barrel cleaning effect will be better.
The customer can use this procedure regularly according to the need.
