Maintenance
Clean detergent box and grooves
Clean detergent drawer and grooves
1.Press down the arrow location on softener cover
inside the drawer.
2.Lift the clip up and take out softener cover and wash
all grooves with water.
3.Restore the softener cover and push the drawer into
position.
Clean inlet filter
Inlet filter shall must be cleaned if there is not any or
insufficient water in when the tap is opened.
Clean the tap filter:
1.Close the tap.
2.Select any procedure except “Wash” or “Drain”
procedure.
3.Press the button “Start/Pause” and keep the
procedure running for about 40 seconds.
4.Remove the inlet pipe from the tap.
5.Use water to wash the filter.
6.Reconnect the inlet pipe.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside of the
machine.
2.Pull out the filter with long nose pliers and reinstall
it back after being washed.
3.Reconnect the inlet pipe.
4.Open the tap and make sure there is no water leakage.
5.Close the tap.
Notes: Generally, the tap filter is washed first and then the filter in washing machine will be washed.
If only the filter in washing machine is washed, then the steps 1~3 in cleaning the tap filter shall be
repeated.
Maintenance
Pull out the power plug to avoid electrical shock before washing.
After using the washing machine, pull out the power cord and close the door tightly to avoid
pinching the kids.
Remove foreign matters
Drain Pump Filter:
Drain pump filter can filter the yarns and small foreign matters from the washings.
Clean the filter periodically to ensure the normal operation of washing machine
.
Cleaning the pump
Important!
According to the soil level within the cycles and the frequency of the cycles,you have to inspect
and clean the filter regularly.
The pump should be inspected if the machine does not empty and/or spin;
the machine makes an unusual noise during draining due to objects such as safety pins,
coins etc. blocking the pump.
1 Disconnect the appliance;
2 If necessary wait until the water has cooled down.
3 Open the service panel .Place a container close to collect any spillage.
4 When no more water comes out, unscrew the pump cover and remove it.
Always keep a rag nearby to dry up spillage of water when removing the cover.
5 Remove any objects from the pump impeller by rotating it.
6 Screw the pump cover fully in.
7 Close the service panel.
Warning!
When the appliance is in use and depending on the programme selected there can be
hot water in the pump. Never remove the pump cover during a wash cycle, always wait
until the appliance has finished the cycle, and is empty. When replacing the cover, ensure
it is securely retightend so as to stop leaks and young children being able to remove it.
First, drain the water with drain pump and then open the drain pump to clean away foreign
matters from drain pump filter.
Take care if the drained water is hot.
Proceed as follows:
Unscrew the pump cover Close the service panel Open the service panel Screw the pump cover
