SnakeSys User Manual 1 / 44
Chapter 1
SnakeSys Products
The SnakeSys Product range currently includes:
SnakeSys B4 A four universe Ethernet to DMX convertor. It supports
four DMX512 ports that are configurable as either inputs or
outputs, and one DMX port that is always assigned as an
input.
SnakeSys R4 A four universe multi-purpose network distribution node
comprising DMX output ports, DMX input ports and
multiple network ports in a 1U rack
SnakeSys T2 A truss mountable two universe Ethernet to DMX
convertor with an in-built network switch. Each universe
has three separate outputs removing the need for a separate
DMX buffer.
SnakeSys R8 An eight universe Ethernet to DMX convertor in a 1U rack.
It supports eight DMX512 ports that are configurable as
either inputs or outputs, and also features dual network
ports.
1.1 SnakeSys Philosophy
SnakeSys network products enable DMX data, media data and control data to be distributed throughout the lighting rig from
control consoles to fixtures. SnakeSys products can be used with any lighting console or media server - they are independent of
MagicQ products.
SnakeSys products are designed and manufactured in the UK using quality electronic components, and are designed for reliability.
Wherever possible, all components are mounted on a single circuit board to avoid the need for interconnecting cables. SnakeSys
products are designed at a "chip" level, rather than repackaging IT products.
SnakeSys products use professional locking Neutrik Ethercon connectors for all network connections, this avoiding the limited
lifetime associated with traditional RJ45 network plugs and sockets.
SnakeSys products use professional locking Neutrik Powercon connectors for power input, ensuring a reliable power input. All
SnakeSys products accept voltages from 90V to 250V AC without needing any changes.
Where appropriate, SnakeSys products have in-built battery backup to protect against unexpected power loss.
SnakeSys products support Power over Ethernet - the SnakeSys B4 and T2 can both be powered directly from the R4 rack nodes
and switches using Power over Ethernet rather than from the mains - this reduces the number of cables in the system.
SnakeSys products support firmware updates over the network, enabling the products to be easily upgraded to support new
features.
