18
2
Hardware Installation
MXM Connector
The MXM connector is used to interface with the carrier board. Insert QB700-B
series to the MXM connector on the carrier board. Refer to the following page for
the pin function of this connector.
Refer to “Installing QB700-B Series onto a Carrier Board” section for more infor-
mation.
MXM Connector
