21
2
Hardware Installation
Installing QB700-B Series onto a Carrier Board
1. The photo below shows the locations of the mounting holes and the bolts al-
ready fi xed in place.
Important:
The carrier board used in this section is for reference purpose only and
may not resemble your carrier board. These illustrations are mainly to
guide you on how to install QB700-B Series onto the carrier board of
your choice.
2. Grasping QB700-B Series by its edges, insert it into the carrier board, and
you will hear a distinctive¨click¨ indicating QB700-B Series is correctly locked
into position.
Mounting hole
QB700-B
Series
Carrier board
Bolts
