IV. PREPARING THE CLEANER FOR USE
Remove all packing items and unpack all accessories. Assemble the cleaner and relevant
accessories (Figure 3a, 3b) according to the intended activity ( dry or wet) hovering/cleaning.
Unlock the cleaner clamp locks (Figure 9), remove the motor part (Figure 10) and take off
the detergent tank (Figure 11). Pull out the dirt flap (Figure 12) from the cleaner body. Insert
the dust bag (Figure 13) in the holder in the cleaner body and check, whether the dust bag is
held fast. Install the hose end-piece in the cleaner intake hole and rotate the hose end-piece
clock-wise until the stop (Figure 17). by following the above procedure in the reverse order,
reassemble the cleaner and shut fast the cleaner clamp locks. The floor tool is intended to
be used to clean different surface types (Figure 4). The accessories can be used as follows:
upholstery tool (Figure 6), cleaner brush (Figure 7), crevice tool (Figure 8). The cleaner can
be carried over obstacles ( such as thresholds or stairs) by using the handle (Figure 47).
V. CLEANING DRY SURFACES
- Accessories used: intake hose with end-piece and handle ( E1), intake tubes (E2), floor tool
( E9), TURbO tool (E10), upholstery tool (E11), brush (E12), crevice tool
( E13), dust bags, (E14), adapter for hard floors (E15).
Assemble the cleaner by following the above procedure. Plug the assembled suction tubes
into the hose handle and install the floor tool (Figure 18, 19) using moderate force. The tool
can be installed on either one or two tubes or on the suction hose handle directly (Figure 3a).
Unwind the desired length of the cord and plug the cord in the socket. The cleaner can be
switched ON/OFF by depressing the MOTOR push-button (Figure 20). The suction power
of the cleaner can be adjusted by rotating the power control ring on the hose handle on
ETA 2865 (Figure 21) and by setting the REGULATION control knob to the desired position
as well as adjusting the control ring on the hose handle on models ETA 7865 (Figures 20,
21). We recommend the minimal suction output for soft fabric (such as curtains). Use the
maximal suction output for flooring (such as load carpets).
Adapter for Cleaning Hard Floors (E15)
Put the front part of the floor nozzle E9 under two notches and then tilt the adapter to the
nozzle and fix (Fig. 5). You will hear a click sound. Disconnect the adapter from the floor
nozzle in reverse order.
5a) Exchanging the Dust Filter
be careful to check and exchange the dust filter regularly. Whenever the cleaner seems to
start losing power check whether or not the dust bag has filled up and exchange it for a new
one if necessary. Dismantle the cleaner by following the procedure described above. Remove
the suction hose end-piece off the cleaner housing (Figure 17), slide the dust filter lips off the
dust filter holder. Taking proper care, take hold of the dust bag with both your hands (Figure
14), remove it from the cleaner housing and dispose of it with regular domestic waste.
CAUTION
- Never use the cleaner to collect dust without the dust filter installed and never put the
dust filter in the waste tank when it is still damp or wet!
- before you vacuum dry impurities, clean the container, the suction hose and the
appliance properly. Thus you will protect the dust filter from destruction.
