Technical Data
Type approval no.
DIN TW 1068 2000
Input
Connection for resistance thermometer Pt 100:
TRG 5-5..., PN 40-160, T
max
251 °C – 540 °C
Output
Two volt-free relay contacts. Max. contact rating with switching voltages of 24 V,
115 V and 230 V a. c.: 4 A resistive, 0.75 A inductive, cos
ϕ
0.5.
Max. contact rating with a switching voltage of 24 V d. c.: 4 A
Contact material: silver, hard-gold plated.
Temperature limit range
Code-switch selectable in steps of 2 °C within a range of 30 °C to 540 °C.
Switching hysteresis
At
MAX
limit: –5 °C
At
MIN
limit: 5 °C
Indicators and adjustors
Two LEDs “Alarm”, one LED “Power supply”,
one code switch for “
MIN
temperature”, one code switch for “
MAX
temperature”.
Mains supply
230 V +/– 10 %, 50/60 Hz.
Special voltage 115 V +/– 10 %, 50/60 Hz or 24 V +/– 10 %, 50/60 Hz.
Power consumption
5 VA
Protection
TRS 5-8 b:
IP 20 to DIN EN 60529
Admissible ambient temperature
0 °C to 55 °C
Case materials
TRS 5-8b:
Base: ABS plastic, black
Cover: polystyrene, highly shock resistant, stone grey, Fig. 3, Fig. 4
Weight
approx. 0.6 kg
Explanatory Notes
– continued –
