20 21
BIOS SETUP BIOS SETUP
Power
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Power Security BootOptions Save & Exit
ACPI Suspend Mode [S3(STR)]
Deep Sleep Support [Enabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt
F7: Load User-defined Defaults
F8: Save as User-defined
F9: Optimized Defaults
(When Access Level is
Administrator)
F10: Save & Exit
ESC: Exit
Select the highest ACPI sleep
state the system will enter when
the SUSPEND button is pressed.
Power
► ACPI Suspend Mode
This item is used to set the energy saving mode of the ACPI function. When you select “S1 (POS)”
mode, the power is always on and computer can be resumed at any time. When you select “S3 (STR)”
mode, the power will be down after a period of time. The status of the computer before it entering STR
will be saved in memory, and the computer can quickly return to previous state when the STR function
wakes.
► Deep Sleep Support
This item is used to enable or disable Deep Sleep Support function. When entering deep sleep mode
system(S4/S5) only can wake up from power button.
► Restore on AC Power Loss
This item appears when “Deep Sleep Support“ is set to “Disabled“. It is used to set which state the PC
will take with when it resumes after an AC power loss.
Security
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Power Security BootOptions Save & Exit
Administrator Password Status Installed
User Password Status Not Installed
Change Supervisor Password
Change User Password
Security option [Setup]
BIOS Write Protect [Enabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt
F7: Load User-defined Defaults
F8: Save as User-defined
F9: Optimized Defaults
(When Access Level is
Administrator)
F10: Save & Exit
ESC: Exit
Valid Keys:
(1)a-z (A-Z)
(2)0~9
(3)11 special keys:-=[];,./
(4)key pad:0-9 support and 5
special keys
Security
► Change Supervisor Password
This item is used to install or change supervisor password.
► Change User Password
This item is used to install or change user password.
Only when there exists an Administrator password, then this setting can be activated.
► Security option
To protect the BIOS from being changed by the unauthorized users, there is a security option provided
for your choice. Only when there exists an Administrator password, then this setting can be activated.
[setup]:A password will be required to enter the BIOS.(Only check password when enter setup)
[Always]:A password will be required to enter both the system and BIOS. (Always check password)
► BIOS Write Protect
To protect the system BIOS, there is a BIOS write-protection mechanism provided to prevent BIOS
FLASH tool being improperly used to update BIOS.
