19
2
19
Intel ® Me Jumper: MfG
This mother�oard uses MFG jumper to ena�le or disa�le Intel® Management Engine function.
Intel® Management Engine (ME) is an em�edded microcontroller located in Intel chipset. It
provides latest IT management features such as Intel® AMT, that allows to improve manage-
ment of corporate assets.
Set the jumper to pins 1-2, you can enable the Intel® Management Engine function.
Set the jumper to pins 2-3, you can disable the Intel® Management Engine function.
Ena�le
(Default)
1
2
3
Disa�le
1
2
3
MfG
Before flashing BIOS ROM, you need to set MFG jumper to pins 2-3 first.
CA
UT
IO
N
!
