Outputs
The two outputs are both volt-free contacts, but their ratings differ. See the appropriate installation guide
for connection details and electrical limits.
Table 13.
Parameter Function
GENERATE
The GENERATE field sets the function of the output by use of the
following keywords:
“Generate”
Keyword
Function
ON Sets the output permanently on.
OFF Sets the output permanently off.
PULSE +
Sets the output to activate once only for the
period defined by the TIMER field, on receipt
of a Recall signal from a remote telephone.
MUTE +
Sets the output to indicate if the audio input is
muted.
RING +
Sets the output to pulse when an incoming
call is ringing. The pulsing on /off periods are
set by the CADENCE field.
CALL +
Sets the output to pulse when an outgoing call
is active. The pulsing on /off periods are set
by the CADENCE field.
CONNECT + Sets the output on when a call is connected.
HOOK +
Sets the output on when the telephone is off
hook, and off when it is back on hook.
INUSE +
Sets the output on when an incoming call
arrives or when the user goes off hook for an
outgoing call, and off when the call ends.
RINGCADENCE +
Causes the output to pulse in time with the
ring tone cadence.
RINGOUT +
Sets the output to pulse when an outgoing call
is ringing (but not yet connected). The
pulsing on /off periods are set by the
CADENCE field.
PAGE +
Sets the output to pulse when a call is present
that has been signaled as a PAGEMODE call.
See UNIT page and refer to Pub. 42004-396
for further information, if required. The
pulsing on /off periods are set by the
CADENCE field.
