Description IPE2500A and IPE2500A-MLS Paging Encoder/Desktop Controller
03/12 4
Feature Benefit
Audio accessory connection Numerous audio accessory options maximize ease-of-use and
productivity.
Modular phone line connection Connector on rear makes telephone line easy to install.
H.E.A.R. (Hospital Emergency
Administration Radio) System
operation Provides selective calling and decoding of DTMF tone codes with
alerting.
Direct DTMF Dialing Allows for one-button generation of DTMF digits from the numeric
keypad to control remote devices and repeaters.
Introduction to the IPE2500A Paging Encoder/Desktop Controller
The IPE2500A Paging Encoder/Desktop Controller provides a cost-effective console-like alternative to
conventional radio control. This standard unit is a “tone” control remote. However, by adding the
optional field installation kits to the IPE2500A and using the CARD Suite Programming Software, it can
be configured for DC, Local, and E&M and tone, allowing further possibilities for remote dispatch.
When used with a compatible remote adapter such as the ITA2000A, the IPE2500A provides dispatch
control. Nearly every aspect of the operation can be programmed using the CARD Suite Programming
Software for specific control needs. The multiple frequency control, two-line LCD display, aliasing
functions, intercom, parallel status updating, programmable voice delay, paging encoder, H.E.A.R., and
multiple desk set support are standard features that provide powerful fixed station control.
Each of the four programmable buttons can be configured to perform two functions. In addition, the four
optional inputs and outputs for the IPE2500A that can be programmed for various uses. With optional
relays, outputs can be configured for On-Air Light, General Purpose Control, “On-Off,” PTT, Vox
Detect, Data Enable, and Guard Tone Detect. Inputs can be configured for Button Remap, E Lead for
E&M, Output Link, and Link to a Page.
The IPE2500A also includes DTMF, 2-Tone, Plectron, and 1500, 2805, and custom 2-Tone paging
formats. Buttons can be configured for preset paging. With the relay control option, the IPE2500A is
capable of local, E&M, and E&M with tone control.
Multi-line Select is available with the IPE2500A. When equipped, the unit is referred to as an
IPE2500A-MLS. This unit provides single or multi-select transmission capability, tone remote control of
two to four base stations, vox detect indication for each line, manual unselect audio mute, mute unselect
audio on transmit, and is two-wire or four-wire compatible.
