Power parameters
There are many possible displays in SET mode, but all
use the format illustrated immediately below. (In contrast,
READ mode, shown at bottom, is always characterized by
a display of all three V, mA, and W values.)
SET mode
Note: The power supply is
in SET mode by default
except when power is being
delivered to a load. Once
the HV output is on (the
start/stop key has been
pressed) SET mode is
selected by pressing the
set/read key. After 5 s of
inactivity, the power supply
switches to the READ mode
automatically.
•
p9
Continuous
Timed Hrs
T/Hold
Timed Vhrs Const Amp
Const Volt
V&mA
Const Watt
#1 Protocol 1
Const Volt 200 V
Timed Hrs
Step 1 10:00 hrs
Protocol number 1–3
Step number 1–3
Hrs:min or Vhrs
Protocol name 13 characters
Step number 1–3
Continuous
Timed Hrs
T/Hold
Timed Vhrs
100Volts 500mA
50Watts
Step 1 10:00 hrs
0:30 Hrs Elap
Hrs:min or Vhrs Elapsed
Output current
Set parameters
Output voltage
Output watts
READ mode
