PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
ITEM NO. PART NUMBER DESCRIPTION QTY.
40 026-01M0924 SHAFT .75" X 1.92" LG. 1
41 026-01M0925 SHAFT .75" X 4.69" LG. 1
42 026-01M0935 1.5" ID ALUMINUM RING 2
43 026-01P2650 CABLE SHIELD 1
44 026-01PL0125-125 E-Z GLIDE PLASTIC SLEEVE 2
45 026-01PL2122 OVAL-SHAPED RUBBER FOOT 2
46 026-01PL2158 1.50" PLASTIC KNOB - BASE 2
47 026-01PL2159 1.50" PLASTIC KNOB - CAP 2
48 011-0107011 5/16"-18UNC X 1.25" HHB (WZ) 2
49 013-0302008 5/16" SAE FLAT WASHER (WZ) 11
50 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 32
51 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 30
52 013-0102022 3/8" INTERNAL LOCK WASHER 12
53 011-0101026 3/8"-16UNC X 1.00" BHCS (WZ) 20
54 011-0407020 3/8"-16UNC X 1.75" HHB (WZ) 2
55 011-0107032 3/8"-16UNC X 2.50" HHB (WZ) 1
56 011-0101005 3/8"-16UNC X .75 SHB (WZ) 2
57 011-0311013 3/8-16UNC X .75" SQUARE HEAD (WZ) 1
58 011-0107034 1/2"-13UNC X 3.25" HHB (WZ) 6
59 011-0107036 1/2"-13UNC X 5.75" HHB (WZ) 3
60 011-0107045 1/2"-13UNC X 1.25" HHB (WZ) 3
61 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 15
62 012-0104008 3/8"-16 UNC THIN NYLOCK NUT (WZ) 11
63 010-01C0357 CABLE ASSEMBLY ROC-IT 101 - 132 11/16"LG. 1
64 ROC-IT WEIGHT CAGE ROC-IT WEIGHT CAGE 1
65 021-0003422 DECAL ROC-IT WEIGHT STACK (1-12) 1
66 026-01P2653 'H' PLATE 1
67 011-0101047 1/2"-13UNC X 1.50" BHCS (WZ) 2
68 026-01P2907 HEAD BRACKET MOUNT 1
69 026-01P2929 BACK BRACKET MOUNT 2
70 022-01PD2073-5 HEAD PAD PLASTIC BACKING 1
71 022-01PD2059-5 PLASTIC BACKING 1
72 011-0107030 1/2"-13UNC X 3.00" HHB (WZ) 1
73 026-01X2975 FOOT PLATE MOUNT ASSEMBLY 2
74 014-0101020 .38" I.D. x .50" OILITE BUSHING 2
75 026-01PL2197 PLASTIC SCUFF GUARD 11.05" LG. 1
76 011-0107029 5/16"-18UNC X 1.00" HHB (WZ) 8
77 026-01M1137 3/8" X 3 1/16" LG. CABLE ANCHOR SHAFT 1
78 012-0102006 5/16"-18UNC THICK NYLOCK NUT (WZ) 2
79 011-0101067 5/16"-18UNC X 1.00" BHCS (WZ) 1
