Page 12
D300
PARTS LIST
CUSTOMER CATALOG
Page 11
1
35-SUB-D300-08
FRONT UPRIGHT
1
Key
No. Qty.
Part Number
Description
2
35-SUB-D300-21
REAR UPRIGHT, RIGHT SIDE
1
3
35-SUB-D300-20
REAR UPRIGHT, LEFT SIDE
1
4
35-SUB-D300-04
BASE TUBE ASSEMBLY
1
5
35-SUB-D300-01
TOP TUBE ASSEMBLY
1
6
35-SUB-D300-22
LOWER REAR CROSSMEMBER
1
7
35-SUB-D300-23
UPPER REAR CROSSMEMBER
1
8
26-STD-SP338
PLACARD MOUNT
1
9
35-SUB-D300-03
TOP PULLEY MOUNT
1
10
35-SUB-D300-11
ARM UNION ASSEMBLY
1
11
35-SUB-D300-07
REAR SHIELD ANCHOR
1
12
35-SUB-D300-09
BACK PAD ADJUSTER MOUNT
1
13
026-0100021
ARM AXLE
1
14
35-SUB-D300-15
HANDLE ASSEMBLY
2
15
35-SUB-D300-16
RIGHT HANDLE PIVOT ASSEMBLY
1
16
35-SUB-D300-17
LEFT HANDLE PIVOT ASSEMBLY
1
17
26-STD-SM239
3/8" FLATHEAD CAP x 1 5/8 DIA.
4
18
35-SUB-D300-14
ARM ASSEMBLY, RIGHT SIDE
1
19
35-SUB-D300-13
ARM ASSEMBLY, LEFT SIDE
1
20
35-SUB-D300-19
HANDLE ASSEMBLY AXLE PIVOT
2
21
26-STD-SU1017
10 x 17 PAD
1
22
026-01MD300-18
HANDLE ASSEMBLY AXLE
2
23
35-SUB-D300-06
BOTTOM GUIDE ROD MOUNT
1
24
35-SUB-D300-02
TOP GUIDE ROD MOUNT
1
25
26-STD-SWTOP-7
TOP PLATE AND STEM
1
26
26-STD-SW101
INTERMEDIATE 12 1/2 LBS.
4
27
26-STD-SW104
INTERMEDIATE 20 LBS.
11
28
26-STD-SSH148
SHIELD
1
29
35-SUB-D300-10
CHEST PAD ADJUSTER
1
30
35-SUB-D300-05
SEAT PAD ADJUSTER
1
