D300
HARDWARE LIST
CUSTOMER CATALOG
A
11-HEX-123
1/2-13 x 3 HEX BOLT
4
Key
No. Qty.
Part Number
Description
B
11-SKT-381
3/8-16 x 1 SOCKET HEAD BOLT
4
C
11-HEX-12212
1/2-13 x 2 1/2 HEX BOLT
12
D
11-HEX-123
1/2-13 x 3 HEX BOLT
5
E
11-HEX-38(16)2
3/8-16 x 2 HEX BOLT
4
F
11-HEX-12312
1/2-13 x 3 1/2 HEX BOLT
2
G
11-HEX-12412
1/2-13 x 4 1/2 HEX BOLT
2
H
11-HEX-383
3/8-16 x 3 HEX BOLT
2
J
11-HEX-38(16)212
3/8-16 x 2 1/2 HEX BOLT
1
K
11-HEX-38312
3/8-16 x 3 1/2 HEX BOLT
1
L
11-HEX-385
3/8-16 x 5 HEX BOLT
1
M
11-FLA-12314
1/2-13 x 3 1/4 FLAT HEAD BOLT
2
N
11-FLA-121
1/2-13 x 1 FLAT HEAD BOLT
7
P
11-FLA-123
1/2-13 x 3 FLAT HEAD BOLT
1
Q
11-NYL-38(16)1
3/8-16 x 1 NYLOCK PATCH BOLT
2
R
11-HEX-381
3/8-16 x 1 HEX BOLT
7
S
11-HEX-516(18)114F
5/16-18 x 1 1/4 HEX BOLT
6
T
13-FLT-12
1/2 FLAT WASHER
50
U
12-LOK-12T
1/2-13 THIN LOCK NUT
29
V
14-TBW-1
THRUST BEARING WASHER, 1"
6
W
14-BRG-THRUST1
THRUST BEARING, 1
2
X
Y
Z
AA
AB
AC
13-FLT-38
13-FND-38112
13-FLT-12SAE
13-FLT-516
12-LOK-38
11-FLA-381
3/8 FLAT WASHER
3/8 FENDER WASHER
1/2 SAE FLAT WASHER
5/16 FLAT WASHER
3/8 LOCK NUT
3/8-16 x 1 FLATHEAD BOLT
23
2
4
6
7
2
AD
11-FLA-12212
1/2-13 x 2 1/2 FLAT HEAD BOLT
1
AE
14-SPC-1(38)
DIA. 3/8 I.D. x 1 LG SPACER
1
AF
14-SPC-12(38)
DIA. 3/8 I.D. x 1/2 LG SPACER
1
