F R A M E A S S E M B L Y
Step 2d
17 - Leg Extension Mount
18 - Leg Extension
19 - Lower Swivel Bracket
20 - Dia. .75 x 2.25 LG CRS
Part Descriptions
E - 1/2”-13UNC x 3 1/4” Hex Bolt
AA - 1/2” Flat Washer
BA - 1/2” Nylok Nut
Hardware Descriptions
Page - 11
HD1400 Assembly
OW N E R S
M A N U A L
Start assembly by sliding (20) into the top of (18) and attach it to
(17). Then slide (20) into the bottom of (18) and attach (19) to (18).
bolts. Check to see that these pivot areas swing freely. If
not, back off Nylock Nut (BA) slightly until both (18) and (19) swing
freely.
Wrench Tighten
