HuddleCamHD HuddlePod Air Big Audio User Manual
Page 11
Ver 1.1 7/15
Specs……………………………………………………………………………………………………………………
Model Number: HP-AIR-BA-BK
Microphone Features
Echo Cancellation
256 channel echo cancellation
Audio Output
Max 18dB w/ auto level control
Noise Cancellation
Intelligent NC up to 16dB
Digital EQ
Built-in Digital EQ for stable audio
Battery Life
6-8 Hours, 4-5 hour charge time
Interface
USB 2.0 & 3.5mm Audio Out
Wireless Speakerphone Specifications
Weight
0.8 lbs (0.4kg)
Size
7” Diameter x 1.5” Height (178mmD x 38.1mmH)
Operating Temperature
32- 104°F (0~40°C), Humidity 20%~85%
Compatibility
MS WIN7/8, Mac 10.5+, ChromeOS, Android 4.4+
USB Cable
Supplied for power + charging only
RF frequency range
2.400 GHz - 2.4835 GHz
Certifications
CE Mark (R & TTE Directive), FCC
Big Audio Module Specifications
Weight
0.95 lbs (0.5kg)
Dimensions
7.7”l x 5.8”w x 1.7”h (196mm x 148mm x 44mm)
Operating Temperature
32 - 104°F (0~40°C), Humidity 20%~85%
RF frequency range
2.400 GHz - 2.4835 GHz
Interface
¼” TRS (Unbalanced Dual Mono)
Certifications
CE Mark (R & TTE Directive), FCC
