Values for error behaviour
0 = pre-operational (only if current state is operational)
1 = no change of state
2 = stopped
3 �� 127 = reserved
7.4.1 Communication parameters (to CiA DS-301)
Error register (1001h)
The error register indicates the general error status of the device� Every bit stands
for an error group� If a bit is set (= 1), at least one error of this group is active at the
moment� The contents of this register are transmitted in every EMCY message�
Error groups
Bits 5���7
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Not used
Communication error
(overrun)
Temperature Voltage
Not used
At least one
error active
Pre-defined error field (1003h)
Every inclination sensor keeps an error list of the last five errors occurred� The
entry 1003h/00h contains the number of error entries in the error field�
All other sub-indices contain all error states occurred in chronological order with
the error last occurred being always found under sub-index 01h�
The oldest error is in the highest available sub-index (value of 1003h/00h) and is
the first to be removed from the list in the case of more than five errors� If an error
occurs, a new error entry is added to 1003h and also communicated via an EMCY
message�
Structure of an error entry
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Emergency error
code
Error register
(object 1001h)
Manufacturer-specific error field
Emergency error code (hex)
Description
00xx
Error reset or no error
10xx
Generic error
31xx
Mains voltage
32xx
Voltage inside the device
41xx
Ambient temperature
42xx
Device temperature
80xx
Monitoring
81xx
Communication
8110
CAN overrun (objects lost)
