Lint Filter . . .
The lint filter is located at the front
of the dryer in the lower part of the
door opening.
CLEAN THE LINT FILTER AFTER
DRYING EACH LOAD. A clean lint
filter ensures efficient drying.
TO REMOVE LINT: Wipe across
the filter with damp fingers.
The lint filter has been screwed
down to prevent clothing from
falling into the air duct. We
recommend that once a year you
remove the two screws and lint
filter and vacuum the area under it.
TO REMOVE THE LINT FILTER:
Remove two screws and lift filter
up and out of door opening. Filter
may be washed if any residue is
noticed on it.
NOTE: Lint filter does not have to
be removed from door opening to
remove lint. We recommend that
you leave it in place except when
cleaning the air duct.
TO REPLACE LINT FILTER:
Place filter in door recess and
push in firmly. Be sure to replace
the filter with the words facing the
front of the dryer. Replace two
screws.
IMPORTANT: The lint filter must
be in place in the door opening
when using dryer or loading and
unloading dryer. If the filter is not in
place, clothing could fall into the
front air duct and get into the
exhaust system, causing damage
to the motor.
Door Liner . . .
Lint can accumulate in the door
liner (opening in bottom of dryer
door). Occasionally open dryer door and
vacuum the door liner.
D244IE3D
LINT
FILTER
DOOR
LINER
