45
3.3 Overview of buttons and indications
3.3.1 Display
A Present speed
B Peddling assistance level
C Battery pack charge level
D Lighting indicator
E Variable indicator
F Variable indictor description
G Temperature/Time
H View Trip 1/Trip 2
I Average speed indicator
3.3.2 Control unit
H Lighting button
I Up button – variable application
J Set – variable application
K Down button – variable application
L Mode button – variable application
3.4 Switching on display
If the up arrow on the lighting button is
pressed, the reading will be displayed.
When the E-bike is not in use, the power
assistance and lighting will switch off
automatically after five minutes. Fifteen
minutes later, the display will automatically
switch to sleep mode and no longer show
an image. To get the display out of sleep
mode, press on or or put the E-bike into
motion.
50%
21 ° C
km/h
18
.
0
13.82km
xxxxxxxxxxxxx
1
2
C
D
H
G
B
E
F
A
I
I
K
H
J
L
90%
21 ° C
km/h
0
.
0
0.00km
