TwinTraveller
The maximum carrying
capacity of the
TwinTraveller is 250 kg.
Setting the handlebar height
Loosen the screws (1A and 1.
1B).
Adjust the handlebar to the
2.
desired height.
Tighten the screws (1A and
3.
1B).
Band brake
The band brake can be operated
by the rear cyclist.
Turn the Gripshift switch (2A) 1.
to activate the band brake.
Use the band brake during
2.
descents to avoid high
speeds.
After the band brake
has been used, the disc
brake can be extremely
hot.
Braking power of the band
brake
Wear can make the band brake
lose its braking power.
Turn the adjustment button 1.
(2B) to adjust the braking
power.
Koga Downhill front fork
Before use, adjust
the front fork to the
intended use and the
weight of the total load.
Rear suspension
Never disassemble the
spring element: it is
under high pressure.
Leave maintenance up
to your Koga dealer.
Folding the TwinTraveller
Put the bicycle on its stand 1.
(4A).
Attach the bag to the left
2.
side of the back carrier (4B).
Disassemble the pedals (4A)
3.
and put them in the bag (4B).
www.koga.com
11
nlnl
dkdk
ukuk
frfr
dede
A A
2x
7 8
A
6
A
A
5
The frame’s own weight
makes it fold slightly.
Fold the frame 30° open (7). 7.
Check that the bicycle
remains sufficiently in
balance if you let go of it
.
The front chain comes loose 8.
(8).
Push the two safety pins (7A) 6.
downwards.
Fold the levers down (5 and 4.
6).
Turn the levers 90° outwards
5.
(5 and 6).
12 11
A
10 9
Pull on the gloves supplied. 9.
Take the chain off the front 10.
chain ring (9).
Mount the chain via the 11.
rollers (10A).
Use the quick release to
12.
tension the chain on the
lower roller.
Fold the TwinTraveller fully 13.
(11).
The TwinTraveller can be 14.
transported by car on the
Uebler bicycle carrier (12).
Follow the instructions in the
manual supplied
