IRT1557
Operating Instructions
- 17 -
Nominal Current 1 mA
Number of
Measurements
per EN615577-2
3000
using
2000mA/Hr Alkaline Batteries
Input Protection 1000V
Circuitry
Protection
test inhibited if ≥ 30V AC or DC at
inputs
Lo Ω
Ω
Ω
Ω
Range
20.00 Ω
Accuracy
2% + 2 digits
Resolution
0.01 Ω
Analog Bar
Graph
0 to 100 Ω and infinity
Open Circuit
Voltage
4V dc nominal
Short Circuit
Current
>200 mA 0–2Ω
Test Leads Zero Zero up to 10 Ω
Number of
Measurements
per EN61557-4
5000
using
2000mA/Hr Alkaline Batteries
Input Protection
1000V
Circuitry
Protection
test inhibited if ≥ 30V AC or DC at
inputs
Resistance Measurement
Range
2000 Ω
Accuracy
5% + 2 digits
Resolution
1 Ω
Analog Bar
Graph
0 to 10 kΩ and infinity
Bar Graph
Accuracy
10%
Beeper
On at ≈30 Ω or less
Test Current
25µA nominal
