Sensoray 2600 Programming Guide
27
Gateway Action Scheduling
will cause the corresponding channel to be programmed for the 100 millivolt measurement range. The following table shows the
relevant attributes for all supported input types. The enumerated input type names are defined in the
App2600.h
header file.
7.4.3 Calibration
Calibration is achieved by storing values in the 2608 module’s EEPROM. Values may be stored in the EEPROM by calling
S26_2608_WriteEeprom()
, and stored values may be retrieved by calling
S26_Sched2608_ReadEeprom()
.
Various EEPROM locations are reserved for calibration values as described in section 7.4.4. All calibration values are multi-byte
values that are stored in little-endian byte order.
7.4.4 Reserved EEPROM Locations
As shown in the following table, the first 176 EEPROM locations are reserved for calibration and configuration data:
7.4.5 S26_Sched2608_SetTempUnits()
Function:
Schedules the setting of temperature units for thermocouple data returned from a model 2608 IOM.
Enumerated Type
Resolution
Data Units
Description
RAW_LG_TYPE
1 count
ADC counts
Corrected ADC counts, 10V range. This is the default type.
RAW_HG_TYPE
1 count
ADC counts
Corrected ADC counts, 100mV range.
V_10_TYPE
320 µV
Volts
Measured voltage, 10V range.
V_001_TYPE
3.2 µV
Volts
Measured voltage, 100mV range.
TC_B_TYPE
0.457 °C @ 800 °C
°C or °F
B thermocouple.
TC_C_TYPE
0.168 °C @ 800 °C
°C or °F
C thermocouple.
TC_E_TYPE
0.0478 °C @ 100 °C
°C or °F
E thermocouple.
TC_J_TYPE
0.0593 °C @ 100 °C
°C or °F
J thermocouple.
TC_K_TYPE
0.0762 °C @ 100 °C
°C or °F
K thermocouple.
TC_N_TYPE
0.107 °C @ 100 °C
°C or °F
N thermocouple.
TC_R_TYPE
0.267 °C @ 800 °C
°C or °F
R thermocouple.
TC_S_TYPE
0.291 °C @ 800 °C
°C or °F
S thermocouple.
TC_T_TYPE
0.0696 °C @ 100 °C
°C or °F
T thermocouple.
Address
Data Type
Description
0
u8
Number of analog output channels present on the 2608 module. This is factory programmed and
should never be changed.
1 to 11
--
Reserved for future use.
12
u32
Exact voltage of 10V reference standard, times 1e6.
16
u32
Exact voltage of 100mV reference standard, times 1e6.
20+6*CHAN
s16
Raw binary value that would be programmed onto analog output channel CHAN in order to produce
exactly zero volts out. This typically has a value between -15 and +15.
22+6*CHAN
u32
Scalar, times 1e6, that is applied to values programmed onto analog output channel CHAN to
compensate DAC full scale error. The scalar value is typically within ±5% of 1.0.
68+2*CHAN
s16
Raw binary value that must be subtracted from on-board reference temperature sensor CHAN to
compensate its offset temperature.
84
u8
Checksum of all stored bytes from address 0 through 83.
85 to 175
--
Reserved for future use.
176 to 255
--
Available for application use.
