45
Par
ts
REEL LIFT CYLINDER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 18-168 Elbow 2
2 HP-18-100 Cotter Pin 1 /
8
x 1 1
3 HCP-12-350 Clevis Pin 1 /
2
x 3 1 /
2
1
4 75-634 Hydraulic Cylinder 1
14-268 Seal Kit 1
TAILGATE CYLINDER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HHP-18 Bridge Pin 1 /
8
1
2 18-168 Elbow 2
3 75-714 Hydraulic Cylinder 1
14-268 Seal Kit 1
4 HNJ-58-18 Jam Nut 5 /
8
- 18 1
5 HNCL -58-11 Center Lock Nut 5 /
8
- 11 1
6 18-154 Rod End 1
HG-14-28-180 Grease Fitting 1 /
4
- 28 x 180° 1
7 HMB-58-14 Machine Bushing 5 /
8
- 14GA 3
8 HB-58-11-200 Bolt 5 /
8
- 11 x 2 1
9 HCP-58-175 Clevis Pin 5 /
8
x 1 3 /
4
1
