Hopper and tailgate parts list, Par ts, Ground dump) – Smithco Sweep Star 48 (sn 4975 – 4982) Parts & Service Manual User Manual
Page 67
65
Par
ts
HOPPER AND TAILGATE PARTS LIST
(GROUND DUMP)
REF#
PART#
DESCRIPTION
QUANTITY
1
48-104
Tailgate
1
2*
48-063
Tailgate Filter Pack
(optional)
1
3
48-115
Adjustable Draw Latch
2
HB-14-20-075
Bolt
1
/
4
- 20 x
3
/
4
4
HNTL-14-20
Lock Nut
1
/
4
- 20
4
4
48-103
Tailgate Cover
1
5
42-040
Yoke
3
/
4
2
HNJ-34-10
Jam Nut
3
/
4
- 10
2
6
HB-12-13-200
Bolt
1
/
2
- 13 x 2
2
HNCL-12-13
Center Lock Nut
1
/
2
- 13
2
HMB-12-14
Machine Bushing
1
/
2
x 14GA
8
7
48-097
Lift Rod
2
8*
48-122
Hopper Filter Pack
(optional)
1
9
48-102
Hopper Cover
1
10
48-091
Left Tower
1
11
HB-38-16-125
Bolt
3
/
8
- 16 x 1
1
/
4
2
HW-38
Washer
3
/
8
2
HNTL-38-16
Lock Nut
3
/
8
- 16
2
12
48-094
Tower Support
1
13
48-078
Grip
1
14
48-090
Right Tower
1
15
76-151
Washer
4
16
HCP-34-175
Clevis Pin
3
/
4
x 1
3
/
4
4
HHP-18
Bridge Pin
1
/
8
4
17
HB-34-10-400
Bolt
3
/
4
- 10 x 4
2
HMB-34-10
Machine Bushing
3
/
4
- 10GA
10
HNTL-34-10
Lock Nut
3
/
4
- 10
2
18
48-116
Gas Spring
2
26-034
Ball Studs 10 mm
4
HWL-516
Lock Washer
5
/
16
4
HN-516-18
Nut
5
/
16
- 18
4
19
HB-12-13-200
Bolt
1
/
2
- 13 x 2
2
HMB-12-14
Machine Bushing
1
/
2
- 14GA
2
HNTL-12-13
Lock Nut
1
/
2
- 13
2
20
48-096
Tailgate Adjuster
2
21
48-098
Right Dump Arm
1
48-099
Left Dump Arm
1
10-025
Flange Bushing
1 per
22
HB-12-13-150
Bolt
1
/
2
- 13 x 1
1
/
2
2
HMB-12-14
Machine Bushing
1
/
2
- 14GA
2
HNTL-12-13
Lock Nut
1
/
2
- 13
2
23
48-053
Tailgate Hinge
2
24
48-101
Hopper
1
25
48-095
Tailgate Dump Handle
1
*
48-121
Dust Filtration Pack Ground Dump
1 per
(includes Ref# 2 and 8)
