Model 58/59 User Guide

Issue 4, December 2000

Studio Technologies, Inc.

Page 59

for Surround

Signal

Signal

Connections

High (+)

Low (–)

Shield

MONITOR OUT A

24

12

25

NOT USED

10

23

11

MONITOR OUT B

21

9

22

NOT USED

7

20

8

METER OUT

18

6 (See Note 3)

19

NOT USED

4

17

5

BYPASS IN

15

3

16

NOT USED

1

14

2

Notes: 1) Connector type on Model 58 is 25-pin D-subminiature

female. Installer must provide plug (male). Connector
uses 4-40 threaded inserts for locking with mating plug.

2) Wiring scheme loosely follows Tascam DA-88
convention. Modified DA-88-type wiring harnesses are
required, along with 4-40 screw threads.

3) Meter output is unbalanced. Pin 6 is internally
connected to Model 58 shield.

Figure 13. Single-Channel Mode Connections
for Monitor Outputs, Meter Output, and Bypass
Input

Signal

Signal

Connections

High (+)

Low (–)

Shield

SEND 1

24

12

25

RETURN 1

10

23

11

NOT USED

21

9

22

NOT USED

7

20

8

SEND 2

18

6

19

RETURN 2

4

17

5

NOT USED

15

3

16

NOT USED

1

14

2

Notes: 1) Connector type on Model 58 is 25-pin D-subminiature

female. Installer must provide plug (male). Connector
uses 4-40 threaded inserts for locking with mating plug.

2) Wiring scheme loosely follows Tascam DA-88
convention. Modified DA-88-type wiring harnesses are

required, along with 4-40 screw threads.

Figure 14. Single-Channel Mode Connections
for Inserts
