8
KS-6002 EQ Compressor
Specifications
Equalizer
Equalizer type 2-band, peaking type, sweepable fre-
quency
Center frequency ranges LOW 200 Hz to 3.2 kHz,
HIGH
1.2 kHz to 15 kHz
Cut and boost ±12 dB
Compressor
Threshold level Settable from 0 dB through +12 dB
Attack time (fixed) 3 ms
Release time (fixed) 300 ms
Ratio (fixed) 2:1
Audio performance figures
(when used with KS-342)
Frequency response 50 Hz to 15 kHz (< ±1.0 dB)
Signal-to-noise ratio (equalizer and
compressor both ON) MIC
–70 > 55 dB (30 kHz LPF/RMS)
LINE +4 > 66 dB (30 kHz LPF/RMS)
Total Harmonic Distortion LINE < 0.5% (50 Hz to 15 kHz, nominal lev-
el, compressor off)
MONI < 0.5% (50 Hz to 15 kHz, nominal
level)
Physical, etc. specifications
(when used with KS-342)
Power consumption 140 mA (with EQ and compressor
both ON)
Battery life when used with KS-342 > 2 hours (manganese)
> 3 hours (alkaline)
> 6 hours (with NP-1 pack)
Dimensions (w x d x h) 215 x 170 x 40 (mm)
8.5 x 6.7 x 1.6 (in)
Weight 800 g (1.8 lbs)
