TS Performance 1110304 - Manual (Page 2)

Continued
Installation of the TS Performance Power Play Mp-8
07.5 Dodge 6.7L
Read all instructions and fully understand them before installing you TS Performance MP-8 module.
Disconnect the battery terminals and remove keys from ignition before installation.
Place Di-Electric Grease onto every electrical connection.
1.
Disconnect the positive
terminals on both
batteries
. Failure to do this will
cause a Check Engine Light and it
will have to be cleared with a code
reader. (Any time the module is
installed or removed, the batteries
must be disconnected.)
2. Remove the dipstick and 4 bolts
holding the plastic cover plate on top
of the engine.
3. Using an 11mm wrench remove the 2
clamps holding the EGR tube that
crosses in front of the valve cover.
You do not have to remove the tube
only tilt the tube up towards the front
of the truck.
4. Using a 10mm socket and wrench,
remove the bolt that holds the dipstick
tube to the bracket and the 6 bolts that
hold the air horn to the manifold.
Making sure not to damage the gasket,
slide the air horn forward so that you
can access the front of the fuel rail.
5. Remove the 18mm fuel rail valve located
on the front of the fuel rail.
6. Take valve and thread supplied nut tool
onto valve. Then place valve in a vice,
clamping down on sides of valve cap.
