LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
NO. QTY. PART NO. DESCRIPTION
1 1 651225P TONGUE ONLY, TUBE MOUNT
2 2 650398P TONGUE ONLY, SNAP RING MOUNT
3 1 650235 JACK SIDE CRANK
4 1 330014 RING, JACK RETAINING SNAP
5 1 101351 TAILLIGHT HARNESS
6 10 032048 1/2-13 LUG NUT
7 2 101050 ATTACHMENT BRACKET
8 1 101052 WELD PLATFORM
9 4 044038 3/8-16 NYLON INSERT NUT
10 1 047025 1/2" FLAT WASHER
11 2 044048 NUT NYLOCK 1/2-13 HEX PL
12 2 046230 BOLT CS 1/2-13 X 5 HEX GR5 PL
13 1 330013 PIN, LOCK, TUBE MOUNT
14 1 032026 KIT, ALXE MOUNT (SHORT SHACKLE)
15 1 712540 CASTING, PINTLE
16 4 047015 3/8 FLAT WASHER
17 2 044043 7/16-14 NYLOCK NUT
18 2 044061 5/8-11 LOCK NUT
19 2 044062 1/2-13 LOCK NUT
20 2 046160 7/16-14 X 1 1/2 HEX BOLT
21 2 046220 1/2-13 X 4" HEX BOLT
22 2 046250 5/8-11 X 4 1/2 HEX BOLT
23 1 330012A JACK HANDLE REPLACEMENT
24 2 049040 SAFETY CHAIN
25 1 712021 BALL COUPLER 2"
26 1 650100 AXLE PRO W/ LEAF SPRINGS AND HUBS
27 2 650387-13 WHEEL-TIRE ASSEMBLY, 13"
28 1 680879 TOP CRANK JACK, TUBE MOUNT
NIGHT-LITE PRO V-SERIES DOMESTIC
C-1F
TONGUE-AXLE
C-1F
