LEGEND:
NS= Not Shown
** =Purchase locally
TLB 220, 225, 325, 425, and 535
P A R T S R E F E R E N C E
NO
REQ’D
PART NO
DESCRIPTION
A-26B
ENGINE AND FRAME ASSEMBLY PARTS
KUBOTA ENGINE MODELS
1
2
042031
8mm X 1.25 X 25mm GRADE 8.8 BOLT
2
6
047005
5/16” SS FLAT WASHER
3
1
15-000046
UNIDRUM THROTTLE BRACKET
4
1
920539
KUBOTA 25 HP DIESEL ENGINE (TLB 425)
15-000252
KUBOTA 20 HP DIESEL ENGINE (TLB 225)
15-000118
7 BLADE FAN
920743
OIL FILTER
15-000125
AIR CLEANER ELEMENT
920751
FUEL SOLENOID
5
1
15-000044
KUBOTA ENGINE MOUNT LEFT
6
8
047015
3/8” FLAT WASHER (AFTER 9/16/97)
7
8
042038
10mm X 1.25 X 20mm GRADE 8.8 BOLT
8
1
920791
HAYES BELL HOUSING SET W/COUPLING
15-000258
HAYES BELL HOUSING SET W/COUPLING, BONDIOLI HYDRO
15-000141
COUPLING PLATE ONLY
9
2
046115
3/8 - 16 NC X 1-1/4 GRADE 5 BOLT
10
2
920283
3/8 COPPER PLATED WASHER
11
2
044101
12 - 20 NF TOP LOCK NUT
12
2
047025
1/2” FLAT WASHER
13
2
043060
5/16 INTERNAL TOOTH LOCK WASHER
14
1
340105
GROUND STRAP
15
1
027025
NEGATIVE BATTERY CABLE
16
1
027025
POSITIVE BATTERY CABLE
16
2
046055
5/15 - 16 NC X 1-1/4 GRADE 5 BOLT
17
1
15-000045
KUBOTA ENGINE MOUNT RIGHT
18
1
920745
SPIN-ON FUEL FILTER (SN 9703T03 TO PRESENT)
19
3
044031
5/16 - 16 NC KEPS NUT
20
1
046010
1/4 - 20 NC X 3/4 GRADE 5 BOLT
21
1
046045
5/16 - 16 NC X 3/4 GRADE 5 BOLT
22
1
92T078
KUBOTA ENGINE THROTTLE LINKAGE ARM
23
1
044023
1/4 - 20 NC NYLOCK NUT
