LEGEND: NS= Not Shown
** =Purchase locally
TLB 220, 225, 325, 425, and 535 P A R T S R E F E R E N C E
NO REQ’D PART NO DESCRIPTION
A-28B
ENGINE AND FRAME ASSEMBLY PARTS
ISUZU ENGINE MODELS
1 1 22-000301 ISUZU 3CD1 DIESEL ENGINE
NS 22-000309 ISUZU 3CD1 DIESEL ENGINE OIL FILTER
NS 22-000310 ISUZU 3CD1 DIESEL ENGINE FUEL FILTER
2 11 042151 10mm SPLIT LOCK WASHER
3 10 042037 10mm X 1.5mm X 20mm GRADE 8.8 BOLT
4 2 22-000106 LEFT/RIGHT ISUZU 3CD1 ENGINE MOUNT
5 1 027027 NEGATIVE BATTERY CABLE
NS 1 027027 POSITIVE BATTERY CABLE
6 3 043090 1/2 INTERNAL TOOTH LOCK WASHER
7 3 047025 1/2 FLAT WASHER
8 4 046434 12mm X 1.75mm X 40mm ALLEN HEAD BOLT
9 4 046436 12mm X 1.75mm X 30mm ALLEN HEAD BOLT
10 2 044026 1/2 - 13 NC SIDE LOCK NUT
11 2 046115 3/8 - 16 NC X 1-1/4 GRADE 5 BOLT
12 2 920283 3/8 COPPER PLATED WASHER
13 1 22-000303 ISUZU 3CD1 HAYES BELLHOUSING KIT
14 8 042027 8mm X 1.25mm X 16mm GRADE 10.9 BOLT
15 8 043055 5/16 SPLIT LOCK WASHER
16 1 22-001000 ISUZU 3CD1 FLYWHEEL COUPLER PLATE
17 2 ** 12mm X 1.75mm HEX NUT
18 1 047015 3/8 FLAT WASHER
19 1 042040 10mm X 1.5mm X 30mm GRADE 8.8 BOLT
20 1 340105 GROUND STRAP
