NO REQ’D PART NO DESCRIPTION
FRONT AXLE INSTALLATION (FWA) PARTS
MODEL TLB 35D
A-7H
LEGEND: NS = Not Shown
** = Purchase locally
1 1 HN075 1 3/4 -12 HEX JAM NUT
2 1 92T152 FRONT AXLE NUT PLATE
3 1 92T100 AXLE PIVOT BOLT BRACKET WELDMENT
4 1 920239 FRONT AXLE ASSEMBLY, FWD
5 2 ** 5/16 FLAT WASHER
6 2 ** 5/16 SPLIT LOCK WASHER
7 2 ** 5/16 - 18 NC X 1 GRADE 5 BOLT
8 AR FW063 1 3/4 I.D. X 2 1/4 O.D. MACHINE BUSHING 18 GA.
AR FW064 1 3/4 I.D. X 2 1/4 O.D. MACHINE BUSHING 14 GA.
AR FW065 1 3/4 I.D. X 2 1/4 O.D. MACHINE BUSHING 10 GA.
9 1 92T002 PIVOT BOLT ASSEMBLY
10 5 401257 1/4 -28 90 ° GREASE ZERK
