Allmand Brothers TLB35D - Manual (Page 69)

ROPS ASSEMBLY PARTS
MODEL TLB 35D
A-14B
LEGEND: NS = Not Shown
** = Purchase locally
NO REQ’D PART NO DESCRIPTION
1 1 92T011 ROPS KIT
(1) FRONT POST ASSEMBLY
(1) REAR POST ASSEMBLY
2 1 920122A 2" LAP BELT KIT
3 1 711028 7/8 O.D. x 9/16 LD. RUBBER GROMMET
4 2 ** 7/16 FLAT WASHER
5 2 ** 7/16 - 20 NF NYLON INSERT NUT
6 2 ** 7/17 - 20 NF x 1 GRADE 5 BOLT
7 1 92T213 TLB LIGHT BRACKET (OPTIONAL)
8 2 920445 TRACTOR IMPLEMENT LIGHT (OPTIONAL)
NS 920123A 3" LAP BELT KIT (OPTIONAL)
NS 1 920427 LIGHT PLATE, 16/3 WIRE HARNESS
IN THE EVENT OF A ROLL OVER OR R.O.P.S. DAMAGE,
THE COMPLETE R.O.P.S. SHOULD BE REPLACED INCLUDING THE HARDWARE.
IF INDIVIDUAL HARDWARE COMPONENTS NEED TO BE REPLACED, THEY CAN BE
SOURCED LOCALLY PROVIDING THEY ARE EQUIVALENT SIZE AND GRADE.
UNDER NO CIRCUMSTANCES SHOULD THE R.O.P.S. EVER BE MODIFIED OR AL-
TERED. IF THIS HAPPENS, CERTIFICATION WILL BE VOID.
