8950DAC Instruction Manual 13
Power Up
Table 3. Input and Output Conditions
Input Signal Standard Detection LED State Output Signal
No signal Auto mode
VID PRES off
625 off
525 off
MAN mode off
FAULT flashing
0 V ±20 mV
No signal Manual mode 525
VID PRES off
625 off
525 on
MAN mode on
FAULT flashing
0 V ±20 mV
No signal Manual mode 625
VID PRES off
625 on
525 off
MAN mode on
FAULT flashing
0 V ±20 mV
Signal present 525 Auto mode
VID PRES on
625 off
525 on
MAN mode off
FAULT off
Valid video output
Signal present 625 Auto mode
VID PRES on
625 on
525 off
MAN mode off
FAULT off
Valid video output
Signal present 525 Manual 525
VID PRES on
625 off
525 on
MAN mode on
FAULT off
Valid video output
Signal present 625 Manual 525
VID PRES on
625 off
525 flashing
MAN mode on
FAULT off
Invalid video output
Signal present 525 Manual 625
VID PRES on
625 flashing
525 off
MAN mode on
FAULT off
Invalid video output
Signal present 625 Manual 625
VID PRES on
625 on
525 off
MAN mode on
FAULT off
Valid video output
